Gear Machines

Farrel Change Gears and Tooling
(PHOTO1) (PHOTO2) (PHOTO3)
Make Offer
Fellows Fine Pitch Gear Shaper No. 3-2
Model No. 3-2, S# 32618, Date Mfg. 1963, Type fine pitch, Size 3", Capacity 3" x 3/4" face fine tooth shaper, 2" Internal capacity, Max helix angle 45º, 4 Speeds 400/700/1200/2000 strokes/min, 1/2hp 208-220/440v 3ph
(PHOTO1) (PHOTO2) (PHOTO3) (PHOTO4) (PHOTO5)

$4,200
Fellow Gear No. 4
S# 31260, 3" x 3/4" Face fine tooth shaper, 2" Internal capacity, Max helix angle 45º, 4 Speeds 400/700/1200/2000 strokes/min, 1/2hp 208/220/440/3ph
(PHOTO1) (PHOTO2) (PHOTO3) (PHOTO4) (PHOTO5)

$4,200 each
Fellow Gear No. 6
Model No. 6, More info coming soon
(PHOTO1) (PHOTO2) (PHOTO3) (PHOTO4)

P.O.R.
Fellows 8 AGS Gear Shaper
Type 8 AGS, S# 33846, Date of Mfg. 1967, Max pitch Dia. internal/external 8", Max Dia. pitch Spur/Helical 5/7" - 6", Max face width internal/external 1.5" - 2", Max stroke 2.25", Max helix angle w/ standard guides 38º - 41, 5hp 230/460v (wired 440v) 3ph, Overall Dim. 5' 6"L x 3' 10"W x 6' 9"H, Est. Wt. 6,750 lbs.
(PHOTO1) (PHOTO2)

$12,000
Fellows 8 AGS Gear Shaper
Type 8 AGS, S# 33960, Date of Mfg. 1967, Max pitch Dia. internal/external 8", Max Dia. pitch Spur/Helical 5/7" - 6", Max face width internal/external 1.5" - 2", Max stroke 2.25", Max helix angle w/ standard guides 38� - 41, 5hp 230/460v (wired 440v) 3ph, Overall Dim. 5' 6"L x 3' 10"W x 6' 9"H, Est. Wt. 6,750 lbs.
(PHOTO1) (PHOTO2) (PHOTO3) (PHOTO4) (PHOTO5)

$12,000
Gleason No. 12 Bevel Gear Generator
Model No. 12, S# 17937, Date of Mfg. 1942, Max Dia. capacity 17", Max rated capacity 3 DP, Extreme ratio 10 to 1, Longest cone distance on 3.5" face is 12", Max face width 3.5", Length of stroke 0.5" to 3.75" w/ 14 ranges, Built in coolant system, Comes with a large assortment of tooling, Overall Dim. 7' 11"L x 5'W x 5' 8"H, Est. Wt. 12,000 lbs., Cleaned & painted
(PHOTO1) (PHOTO2) (PHOTO3) (PHOTO4) (PHOTO5) (PHOTO6) (PHOTO7) (PHOTO8) (PHOTO9) (PHOTO10) (PHOTO11) (PHOTO12) (PHOTO13) (PHOTO14) (PHOTO15) (PHOTO16) Tooling (PHOTO1) (PHOTO2) (PHOTO3) (PHOTO4) (PHOTO5) (PHOTO6) (PHOTO7) (PHOTO8) (PHOTO9) (PHOTO10) (PHOTO11) (PHOTO12) (PHOTO13) (PHOTO14) (PHOTO15) (PHOTO16) (PHOTO17) (EBAY)

$25,000
