STANDARD FEATURES include the following -
Electric/hydraulic operation, all parts standard off the shelf, fabricated
from heavy duty structural steel, CSA and electric safety authority certified, Large work table - ergonomic work height, Bolster plate, Panel mounted
pressure gage, Pressure regulator valve inf variable, Safety Valve for over
load protection, smooth responsive hand control valve, Large self contained
hydraulic reservoir, automotive type oil filter, Dual Acting Cylinder,
Extra long ram stroke, long &flat nose ram adapter, Mechanically adjustable
Head Height, Sight Glass & temp gage |
List
of H Frame Models All prices on request |
25 ton
model Press-it 25, Ram 2", stroke 12", Distance between uprights 27" Ram speed 3 advance/ press 6 inch/sec, weight 900lbs, 1 hp 115v 1ph |
50 ton
model Press-it 50, Ram 3", stroke 12", Distance between uprights 36", Ram speed 2 advance/press 7 inch/sec, weight 1,500lbs, 5 hp 230v |
75 ton
model Press-it 75, Ram 3", stroke 12", Distance between uprights 36", Ram speed 4 advance/press 9 inch/sec, weight 1,700 lbs, 5 hp 230v |
100 ton
model Press-it 100, Ram 3.5", stroke 12", Distance Between uprights 42", Ram speed 4 advance/press 7 inch/sec, weight 2,900, 5 hp 230v |
125 ton
model Press-it 125, distance between uprights 42",5 hp 230v |
150 ton
model Press-it 150, Ram 4.5", stroke 16", Distance between uprights 42", Ram Speed 5 advance/press 9 inch/sec, weight 3,700 lbs, 5 hp 230v |
Optional Features All prices on request |
POWER HEAD
RAISER
FLOW
CONTROL
STROKE
CONTROL
STANDARD RAM
EXTENSION
CARTRIDGE OIL
FILTER
CUSTOM TABLE
SIZES
CUSTOM MACHINE
DESIGN
ASSORTED TOOLING |
FOOT PEDAL WITH ELECTRONIC SOLENOID
ADJUSTABLE CYLINDER
POSITION
STANDARD BOLSTER
PLATE
ADJUSTABLE WORK
LAMP
CUSTOM
BOLSTER
CUSTOM MACHINE
TONNAGE
CUSTOM ELECTRICAL
(WIRED TO YOUR VOLTAGE)
SAFETY
CURTAIN/MATTING |
Cajoromi also sells a full
line of C Frame Presses and 4 Post Presses please inquire if you're looking
for one!

|
|
